    Sunport C6 III MWT Mono Half Cut Solar Cell Module Panel Array Eff. 20.9% 370w 375w 380w 385w 390w

    Ask Lasest Price
    Brand Name : Sunport
    Model Number : AH7H
    Certification : CGC,ISO9001:2015,TUV SUD,PV,CNAS,
    Price : $0.17~0.20/Watt
    Payment Terms : L/C, D/A, D/P, T/T, Western Union, MoneyGram
    Supply Ability : 200000 Watt/Watts per Week
    Delivery Time : To be negotiated
    • Product Details
    • Company Profile

    Sunport C6 III MWT Mono Half Cut Solar Cell Module Panel Array Eff. 20.9% 370w 375w 380w 385w 390w

    Sunport C6 III MWT Mono Half-Cut Solar Cell Module Panel Array Eff. 20.9% 370w 375w 380w 385w 390w Solar Module Panel

    The Sunport C6 III MWT Mono Half-Cut solar panels are advanced photovoltaic modules that utilize Metal Wrap Through (MWT) technology and a half-cut cell design to maximize energy production. Available in power outputs ranging from 370W to 390W, these panels offer efficient and reliable performance for various residential, commercial, and industrial applications.


    The panels feature advanced anti-reflective glass and cell surface texturing, enhancing light absorption and increasing energy production, even in low-light conditions. This makes them highly efficient and productive, allowing for maximum energy generation throughout the day.


    Specification

    Sunport C6 III MWT Mono Half Cut Solar Cell Module Panel Array Eff. 20.9% 370w 375w 380w 385w 390w

    Sunport C6 III MWT Mono Half Cut Solar Cell Module Panel Array Eff. 20.9% 370w 375w 380w 385w 390wSunport C6 III MWT Mono Half Cut Solar Cell Module Panel Array Eff. 20.9% 370w 375w 380w 385w 390w

    Product Paramenters

    Max-Power(Pm)
    365w
    370w
    375w
    380w
    385w
    Power Tolerance
    0~+5
    Max-Power Voltage(Vm)
    34.9
    35.1
    35.3
    35.5
    35.7
    Max-Power Current(lm)
    10.46
    10.54
    10.62
    10.70
    10.78
    Open-Circuit Voltage(Voc)
    42.4
    42.6
    42.8
    43.0
    43.2
    Short-Circuit Current(lsc)
    11.09
    11.16
    11.23
    11.30
    11.35
    Module Efficiency(qm)
    20.7
    21.0
    21.2
    21.5
    21.8
    Operating Temperature(°C)
    -40℃~+85℃
    Maximum system voltage
    DC1500V(IEC)
    Maximum series fuse rating
    15A
    Temperature coefficients of Pmax
    -0.36%/°C
    Temperature coefficients of Voc
    -0.28%/°C
    Temperature coefficients of Isc
    0.06%/°C
    Nominal operating cell temperature(NOCT)
    43±2°C

    TECHNOLOGY COMPARISON
    Compared with conventional module, MWT modules reduce 3% shaded area with no busbars. MWT module technology replaces string ribbon by conductive back sheet, abandoning strain, micro-crack and results power degradation, greatly improving stability and reliability.
    — Structural Feature —
    MWT
    Positive and negative electrodes are both on the rear side of solar cell
    Conventional
    Positive and negative electrodes are located on opposite sides of the cell
    — Cell Structure —
    MWT
    Busbar-free design exhibits higher power output by decreasing shading area up to 3 %
    Conventional
    Conventional design covers more cell surface from the main busbars, therefore the power output is limited
    — Module Encapsulation —
    Replace conventional soldering with conductive foil and 2D encapsulation structure
    Conventional Cells connected by string ribbons



    FAQ
    Q:Are you a factory or a trading company?
    A:We are a professional Solar Panels Manufacturer in China
    Q:How can we guarantee the products quality?
    A:Always provide the esteemed buyer a pre-production sample before mass production; Always testing every product before despatching the shipments;
    Q:What products we can supply you?
    A:Solar Panel,Inverter,Mounting System,Battery,Pv Cable,Distributor Box,Pv Connector,Etc

    Q:Can the products pricing be cheaper?
    A:Of course, you will be offered a a very good discount with large quantities.
    Q: Can print our company‘s logo on the pv panels?
    A:Yes! And we accept the OEM&ODM orders.
