| Model Number : | TSM-DEG18C.20 |
| Price : | To be negotiated |
| Payment Terms : | L/C, D/A, D/P, T/T, Western Union, MoneyGram |
| Supply Ability : | 200000 Watt/Watts per Week |
| Delivery Time : | To be negotiated |
| Brand Name : | TSM-DEG18C.20 |
| Certification : | CGC，ISO9001:2015，TUV SUD，PV，CNAS， |
Trina Solar Panel Paneles Solares Costo 525W 530W 535W 540W 545W Half Cells
➤ Effectively reduce system BOS costs, achieve lower cost of electricity, and improve project profitability
➤ Lower first-year and year-to-year decay values, 30-year power
generation warranty
➤ Compatible with mainstream system designs
➤ Higher return on investment
➤ Application of 210MM large wafer technology, and innovative
three-split module technology
➤ Application of high density module technology, module efficiency
increased to 21.0%
➤ Multi-Main-Barrier (MBB) technology to improve optical
utilization and reduce internal current loss
➤ Excellent IAM and low light response performance verified by
third parties
➤ Lower temperature coefficient (-0.34%) and lower operating
temperature for more power generation
➤ Unique layout design provides greater resistance to shadow
shading
➤ Double-sided power generation with up to 25% increase in back
side power generation depending on the installation environment
| Model No. | 480 | 485 | 490 | 495 | 500 | 505 |
| Warranty | ||||||
| Product Warranty | 12 Years | |||||
| Power Warranty | 30 Years of 85% Output Power | |||||
| Electrical Data at STC | ||||||
| Maximum Power (Pmax) | 480 Wp | 485 Wp | 490 Wp | 495 Wp | 500 Wp | 505 Wp |
| Voltage at Maximum Power (Vmpp) | 42.2 V | 42.5 V | 42.8 V | 43.1 V | 43.4 V | 43.7 V |
| Current at Maximum Power (Impp) | 11.38 A | 11.42 A | 11.45 A | 11.49 A | 11.53 A | 11.56 A |
| Open Circuit Voltage (Voc) | 50.7 V | 50.9 V | 51.1 V | 51.3 V | 51.5 V | 51.7 V |
| Short Circuit Current (Isc) | 11.97 A | 12.01 A | 12.05 A | 12.09 A | 12.13 A | 12.17 A |
| Panel Efficiency | 19.90% | 20.10% | 20.30% | 20.50% | 20.70% | 21% |
| Power Tolerance (Positive) | 1% | 1% | 1% | 1% | 1% | 1% |
| Standard Test Conditions (STC): air mass AM 1.5, irradiance 1000W/m2, cell temperature 25°C | ||||||
| Electrical Data at NOCT | ||||||
| Maximum Power (Pmax) | 362 Wp | 366 Wp | 369 Wp | 373 Wp | 377 Wp | 381 Wp |
| Voltage at Maximum Power (Vmpp) | 38.7 V | 40 V | 40.2 V | 40.5 V | 40.7 V | 41 V |
| Current at Maximum Power (Impp) | 9.11 A | 9.15 A | 9.18 A | 9.22 A | 9.26 A | 9.29 A |
| Open Circuit Voltage (Voc) | 47.7 V | 47.9 V | 48 V | 48.2 V | 48.4 V | 48.5 V |
| Short Circuit Current (Isc) | 9.65 A | 9.68 A | 9.71 A | 9.74 A | 9.78 A | 9.81 A |
| Temperature | 43±2 °C | |||||
| Nominal Operating Cell Temperature (NOCT): 800W/m2, AM 1.5, windspeed 1m/s,ambient temperature 20°C | ||||||
| Thermal Ratings | ||||||
| Operating Temperature Range | 40~85 °C | |||||
| Temperature Coefficient of Pmax | 0.34 %/°C | |||||
| Temperature Coefficient of Voc | 0.25 %/°C | |||||
| Temperature Coefficient of Isc | 0.04 %/°C | |||||
| Maximum Ratings | ||||||
| Maximum System Voltage | 1500 V | |||||
| Series Fuse Rating | 25 A | |||||
| Material Data | ||||||
| Panel Dimension (H/W/D) | 2187x1102x35 mm | |||||
| Weight | 30.1 kg | |||||
| Cell Type | Bifacial | |||||
| Cell Number | 150 | |||||
| Glass Type | Anti-reflection Coating, Tempered | |||||
| Glass Thickness | 2 mm | |||||
| Encapsulant Type | EVA | |||||
| Frame Type | Anodized Aluminium Alloy | |||||
| Junction Box Protection Class | IP 68 | |||||
| Connector Type | MC4 | |||||
| Cable Crossection | 4 mm2 | |||||
➤15 year product warranty
➤ 25 year performance warranty with lowest degradation;
➤Minimized micro-cracks with innovative non-destructive cutting
technology
➤Ensured PID resistance through cell process and module material
control
➤Mechanical performance up to 6000 Pa positive load and 4000 Pa
negative load
|
|
