    390W 395W Module Jinko Solar 400W 405W 410W Half Cell Rooftop Solar System With CE TUV

    Ask Lasest Price
    Model Number : Tiger 66TR(390-410W)
    Price : To be negotiated
    Payment Terms : L/C, D/A, D/P, T/T, Western Union, MoneyGram
    Supply Ability : 200000 Watt/Watts per Week
    Delivery Time : To be negotiated
    Brand Name : Jinko solar
    Certification : CGC,ISO9001:2015,TUV SUD,PV,CNAS,
    • Product Details
    • Company Profile

    390W 395W Module Jinko Solar 400W 405W 410W Half Cell Rooftop Solar System With CE TUV

    390W 395W 400W 405W 410W China Half Cell Solar Panel Roof Tiles Photovolta Panel with CE TUV Certification

    In conclusion, the numerous advantages associated with PERC solar panel technology make it an attractive choice for those seeking an efficient, reliable, and environmentally friendly energy solution. With higher efficiency, improved performance in low-light conditions, lower temperature coefficients, reduced installation costs, long-term durability, ongoing advancements, environmental sustainability, versatility in mounting options, and government support, PERC solar panels continue to gain popularity among homeowners and businesses worldwide as they strive towards a cleaner and more sustainable future.


    Cell Type
    P type Mono-crystalline
    No.of cells
    132 (2×66)
    Dimensions
    1855×1029×30mm (73.03×40.51×1.18 inch)
    Weight
    20.8kg (45.86 lbs)
    Front Glass
    3.2mm,Anti-Reflection Coating,
    High Transmission, Low Iron, Tempered Glass
    Frame
    Anodized Aluminium Alloy
    Junction Box
    IP68 Rated
    Output Cables
    TUV 1x4.0mm2
    (+): 290mm , (-): 145mm or Customized Length
    Model No.JKM390M-6RL3/JKM390M-6RL3-VJKM395M-6RL3/JKM395M-6RL3-VJKM400M-6RL3/JKM400M-6RL3-VJKM405M-6RL3/JKM405M-6RL3-VJKM410M-6RL3
    Warranty
    Product Warranty12 Years
    Power Warranty25 Years of 84.8% Output Power
    Electrical Data at STC
    Maximum Power (Pmax)390 Wp395 Wp400 Wp405 Wp410 Wp
    Voltage at Maximum Power (Vmpp)36.49 V36.58 V36.67 V36.76 V36.84 V
    Current at Maximum Power (Impp)10.69 A10.8 A10.91 A11.02 A11.13 A
    Open Circuit Voltage (Voc)43.75 V43.93 V44.12 V44.2 V44.29 V
    Short Circuit Current (Isc)11.39 A11.48 A11.57 A11.68 A11.79 A
    Panel Efficiency20.43%20.69%20.96%21.22%21.48%
    Power Tolerance (Positive)3%3%3%3%3%
    Standard Test Conditions (STC): air mass AM 1.5, irradiance 1000W/m2, cell temperature 25°C
    Electrical Data at NOCT
    Maximum Power (Pmax)290 Wp294 Wp298 Wp301 Wp305 Wp
    Voltage at Maximum Power (Vmpp)33.666 V33.82 V33.86 V33.97 V34.04 V
    Current at Maximum Power (Impp)8.62 A8.69 A8.79 A8.87 A8.96 A
    Open Circuit Voltage (Voc)41.29 V41.47 V41.64 V41.72 V41.8 V
    Short Circuit Current (Isc)9.2 A9.27 A9.34 A9.43 A9.52 A
    Temperature45±2 °C
    Nominal Operating Cell Temperature (NOCT): 800W/m2, AM 1.5, windspeed 1m/s,ambient temperature 20°C
    Thermal Ratings
    Operating Temperature Range40~85 °C
    Temperature Coefficient of Pmax0.35 %/°C
    Temperature Coefficient of Voc0.28 %/°C
    Temperature Coefficient of Isc0.048 %/°C
    Maximum Ratings
    Maximum System Voltage1500 V
    Series Fuse Rating20 A
    Material Data
    Panel Dimension (H/W/D)1855x1029x30 mm
    Weight20.8 kg
    Cell TypeMonocrystalline
    Cell Number132
    Glass TypeAnti-reflection Coating, Tempered
    Glass Thickness3.2 mm
    Frame TypeAnodized Aluminium Alloy
    Junction Box Protection ClassIP 68
    Cable Crossection4 mm2


    FAQ
    Q:Are you a factory or a trading company?
    A:We are a professional Solar Panels Manufacturer in China
    Q:How can we guarantee the products quality?
    A:Always provide the esteemed buyer a pre-production sample before mass production; Always testing every product before despatching the shipments;
    Q:What products we can supply you?
    A:Solar Panel,Inverter,Mounting System,Battery,Pv Cable,Distributor Box,Pv Connector,Etc

    Q:Can the products pricing be cheaper?
    A:Of course, you will be offered a a very good discount with large quantities.
    Q: Can print our company‘s logo on the pv panels?
    A:Yes! And we accept the OEM&ODM orders.
