Sunport Power S-FLEX 6 360-380W MWT Flexible Module Design Full Black Solar Panel Production Line

Monocrystalline solar panels have become increasingly popular as a highly efficient and long-lasting renewable energy solution. Constructed using a single crystal structure, these solar panels provide greater purity and efficiency than alternative panel options. The enhanced efficiency of monocrystalline solar panels enables them to produce more power per square foot, making them perfect for space-conscious individuals or those aiming to maximize energy production. The sleek black appearance of these panels is also favored by many consumers. Recognized for their durability and lengthy lifespan, monocrystalline solar panels are a smart investment for anyone looking to benefit from solar energy.

Electrical Characteristics at Standard Test Conditions(STC)
Spec/Model	Unit	SPP360QHES	SPP365QHES	SPP370QHES	SPP375QHES	SPP380QHES
Max-Power(Pm)	W	360	365	370	375	380
Power Tolerance	W	0~5%
Max-Power Voltage(Vm)	V	34.7	34.9	35.1	35.3	35.5
Max-Power Current(lm)	A	10.37	10.46	10.54	10.62	10.70
Open-Circuit Voltage(Voc)	V	42.4	42.6	42.8	43.0	43.2
Short-Circuit Current(lsc)	A	10.94	11.02	11.10	11.18	11.26
Module Efficiency(qm)	%	20.4	20.7	21.0	21.2	21.5

TECHNOLOGY COMPARISON

Compared with conventional module, MWT modules reduce 3% shaded area with no busbars. MWT module technology replaces string ribbon by conductive back sheet, abandoning strain, micro-crack and results power degradation, greatly improving stability and reliability.

— Structural Feature —

MWT

Positive and negative electrodes are both on the rear side of solar cell

Conventional

Positive and negative electrodes are located on opposite sides of the cell

— Cell Structure —

MWT

Busbar-free design exhibits higher power output by decreasing shading area up to 3 %

Conventional

Conventional design covers more cell surface from the main busbars, therefore the power output is limited

— Module Encapsulation —

Replace conventional soldering with conductive foil and 2D encapsulation structure

Conventional Cells connected by string ribbons
