    Canadian Monocrystalline Solar Panel Shingled 530W 535W 540W 545W 550W 555W

    Ask Lasest Price
    Model Number : HiKu6-CS6W-MS
    Price : $0.18~0.20/Watts
    Payment Terms : L/C, D/A, D/P, T/T, Western Union, MoneyGram
    Supply Ability : 200000 Watt/Watts per Week
    Delivery Time : To be negotiated
    Brand Name : HiKu6-CS6W-MS
    Certification : CGC,ISO9001:2015,TUV SUD,PV,CNAS,
    • Product Details
    • Company Profile

    Canadian Monocrystalline Solar Panel Shingled 530W 535W 540W 545W 550W 555W

    Canadian 530W 535W 540W 545W 550W 555W Solar Panel Shingled For Home Solar System Using PV Module Bifacial Solar Panel​

    Canadian Solar offers a range of high-quality solar panels with power outputs ranging from 530W to 555W. These solar panels are designed to efficiently convert solar energy into electricity, providing reliable and sustainable power generation for various applications.


    Power Output: The Canadian Solar panels in this range offer a wide power output range, allowing for significant electricity generation capacity. With power outputs ranging from 530W to 555W, these panels are suitable for residential, commercial, and utility-scale installations.


    High Efficiency: The panels are built with advanced solar cell technology to maximize energy conversion efficiency. By capturing and converting more sunlight into electricity, these panels can generate higher power outputs, resulting in increased energy production and improved overall system performance.

    Reliable Performance: Canadian Solar is known for producing high-quality and reliable solar panels. These panels undergo rigorous quality control processes and are built to withstand various environmental conditions. They are designed to deliver consistent performance over their lifespan, ensuring reliable power generation for years to come.

    Model No.CS6W-530MSCS6W-535MSCS6W-540MSCS6W-545MSCS6W-550MSCS6W-555MS
    Warranty
    Product Warranty12 Years
    Power Warranty25 Years of 84.8% Output Power
    Electrical Data at STC
    Maximum Power (Pmax)530 Wp535 Wp540 Wp545 Wp550 Wp555 Wp
    Voltage at Maximum Power (Vmpp)40.9 V41.1 V41.3 V41.5 V41.7 V41.9 V
    Current at Maximum Power (Impp)12.96 A13.02 A13.08 A13.14 A13.2 A13.25 A
    Open Circuit Voltage (Voc)48.8 V49 V49.2 V49.4 V49.6 V49.8 V
    Short Circuit Current (Isc)13.8 A13.85 A13.9 A13.95 A14 A14.05 A
    Panel Efficiency20.70%20.90%21.10%21.30%21.50%21.60%
    Power Tolerance (Positive)2%2%2%2%2%2%
    Standard Test Conditions (STC): air mass AM 1.5, irradiance 1000W/m2, cell temperature 25°C
    Electrical Data at NOCT
    Maximum Power (Pmax)397 Wp401 Wp405 Wp409 Wp412 Wp416 Wp
    Voltage at Maximum Power (Vmpp)38.3 V38.5 V38.7 V38.9 V39.1 V39.3 V
    Current at Maximum Power (Impp)10.38 A10.42 A10.47 A10.52 A10.55 A10.59 A
    Open Circuit Voltage (Voc)46.1 V46.3 V46.5 V46.7 V46.9 V47.1 V
    Short Circuit Current (Isc)11.13 A11.17 A11.21 A11.25 A11.29 A11.33 A
    Temperature41±3 °C
    Nominal Operating Cell Temperature (NOCT): 800W/m2, AM 1.5, windspeed 1m/s,ambient temperature 20°C
    Thermal Ratings
    Operating Temperature Range40~85 °C
    Temperature Coefficient of Pmax0.34 %/°C
    Temperature Coefficient of Voc0.26 %/°C
    Temperature Coefficient of Isc0.05 %/°C
    Maximum Ratings
    Maximum System Voltage1500 V
    Series Fuse Rating25 A
    Material Data
    Panel Dimension (H/W/D)2261x1134x30 mm
    Weight27.6 kg
    Cell TypePERC
    Cell Number144
    Glass TypeAnti-reflection Coating, Tempered
    Glass Thickness3.2 mm
    Frame TypeAnodized Aluminium Alloy
    Junction Box Diodes3
    Junction Box Protection ClassIP 68
    Connector TypeMC4
    Cable Crossection4 mm2
    Cable Length410 mm


    FAQ
    Q:Are you a factory or a trading company?
    A:We are a professional Solar Panels Manufacturer in China
    Q:How can we guarantee the products quality?
    A:Always provide the esteemed buyer a pre-production sample before mass production; Always testing every product before despatching the shipments;
    Q:What products we can supply you?
    A:Solar Panel,Inverter,Mounting System,Battery,Pv Cable,Distributor Box,Pv Connector,Etc

    Q:Can the products pricing be cheaper?
    A:Of course, you will be offered a a very good discount with large quantities.
    Q: Can print our company‘s logo on the pv panels?
    A:Yes! And we accept the OEM&ODM orders.
